dentree · Posted: Wed Jan 28, 2015 1:05 pm Post subject: Barco Cine 8

Hi Casey.
Yes I did see the ad for the Cine 7, but did not imagine that would be considered as an upgrade from my point of view, but I was wondering about the Quad, EHT and splitter, but did not know whether they would be of any use to me, also with regard to the HD145 (I assume that the Cine7 is a 7" machine), in which case the lenses would fit that machine without any mods as the lens bases would be correspondingly smaller to suit the 7" tubes (yes/no?)

Will have another look at it although I think I might have emptied the coffers somewhat with the Canadian purchase, but It was absolutely essential to get back up and running again,
I will check in on you later
Regards
Trev
PS: hope you are begining to feel better as the days pass

cosaw · Posted: Wed Jan 28, 2015 2:13 pm Post subject:

CasetheCorvetteman · Joined: 09 Nov 2008 Posts: 6326 Location: Australia

Trev im not sure what you mean about the Cine 7 mate?? Its an ES focusing entry level set, not sure what use itll be to you.

CasetheCorvetteman · Joined: 09 Nov 2008 Posts: 6326 Location: Australia

dentree · Posted: Thu Jan 29, 2015 2:30 am Post subject:

Sorry Casey It was Hulio who sent me that post, for some reason I thought it was you, please rewind/delete/erase or whatever............ more to the point, recuperation going well?
Regards
Trev

CasetheCorvetteman · Joined: 09 Nov 2008 Posts: 6326 Location: Australia

Getting there thanks mate yeah, still a bit of trouble getting around, and still abit swollen in the stomach which is quite uncomfortable at times, but im getting better.

Hulio · Joined: 15 Apr 2006 Posts: 494 Location: Belgium

Ok, NOW i see where the Cine 7 came in!!
[/quote]

Yepp, that was me...
Ofcourse Cine 7 is a 7" ES machine. I was only saying quad, splitter and lenses for 100 bucks could be right. I remember Trev talking about changing his non colour filtered HD8's with colour filtered HD145's. It was not about downgrading to Cine 7, size do matters guys.... Very Happy

@ Trev
I don't recall if you already mensioned the part nr. of the splitter in the Cine 8. It is R762718 right ? Because if is the old style R7617447, the quads will keep oscillating and get warm.

CasetheCorvetteman · Joined: 09 Nov 2008 Posts: 6326 Location: Australia

Yeah mate i knew you meant all those items, but he allready has a good set of HD-145s there, and a non working Cine 7 may not have a working HV section Wink

The fact is though, $100 is a rort for a Cine 7 here that isnt perfect, its just a fact. I know and respect what youre saying Hulio, but it's the principle!! $100 for a dead Barco to 'maybe' get a quad and splitter, VS a few more bucks and get a much better CRT in working order, or buy known good parts.

If the Cine 7 was $20, absolutely, if it was $50, maybe, if we knew the owner and it could be vouched for, even better, if Trevor was a retro gamer that could sure make good use out of a 7" ES focusing set for some 15.7kHz RGB action, possibly, but $100 for another boat anchor, and Trevor doesnt even have a boat!!

dentree · Posted: Thu Jan 29, 2015 9:11 am Post subject:

Ok Hulio, I now understand what you were getting at, Firstly I already have a set of HD 145 color corrected lenses, it's the adapter plate problem I have to deal with.

the splitter I did change with the one out of the BG 808 to test it against the CINE 8, it seemed OK in the CINE 8 so I have left it in there, but maybe if the numbers do not add up I should possibly change it back to the original, I suppose that because there seems to be a selection of non original parts/boards in this thing, that even the one that I took out might not be original either.

At this point I do not know the part numbers on either one, I will pull them out and have a look, but because of a previous post it was mentioned that all the splitters were pretty much compatible with all these projectors, but now after reading what you have said I shall check

As far as the CINE 7 goes I did not know whether the Quad would have been of any use to me, and obviously I have no idea as to the usefulness of any other parts in the CINE 7, but will keep you informed as to the pedigree of the splitters.

Thanks Hulio

Regards

Trev

dentree · Posted: Thu Jan 29, 2015 9:27 am Post subject:

Hulio,
In fact the splitter that I took out of the CINE 8 has what I think is the old number which reads: 7617447 / 5 / 9441
That is the complete line of numbers,There is NO "R" prefix

So now I am wondering what number I might find on the Splitter (currently installed) in the CINE 8 (Ex BG 808) I cannot imagine that it will in any way correspond to the numbers you have mentioned, that being the case then it would suggest that I have a further possible issue to deal with??

dentree · Posted: Thu Jan 29, 2015 9:39 am Post subject: Barco Cine 8

A boat???.................................I don't even have a trailer, or a towbar !!!!
But there is a Catamaran in the docks in Melbourne which I think will be going very,very cheap Could be a good buy there, as far as I can see the only thing wrong with it is the fact that 3 days ago it burnt to the waterline...........but it is still afloat, what do ya reckon Casey..........................should I dump the projector idea and become a boat owner ???!!!!!

Hulio · Joined: 15 Apr 2006 Posts: 494 Location: Belgium

Forget Barco's, get that boat ( now the spanish forum members are confuse as hell, barco means boat in spanish ).
I take a long holiday, we pick up Case and fix that boat. I'll love to see the Gold Coast again...
About the splitter : 7617447 is a NO GO with the new style quad, EHT and chassis. That's why your second quad got smoked too.

CasetheCorvetteman · Joined: 09 Nov 2008 Posts: 6326 Location: Australia

Sounds like a plan Hulio, although ive got 5 and a bit weeks to go on a 5kg lift limit!!

dentree · Posted: Thu Jan 29, 2015 12:13 pm Post subject:

Ok Hulio, I have the Quad numbered R762717 coming from Canada,also another EHT number R7627165
What Splitter do I need now so the F*****g thing does not end up looking like that boat !!

dentree · Posted: Thu Jan 29, 2015 12:13 pm Post subject:

Ok Hulio, I have the Quad numbered R762717 coming from Canada,also another EHT number R7627165
What Splitter do I need now so the F*****g thing does not end up looking like that that boat !!

dentree · Posted: Thu Jan 29, 2015 12:14 pm Post subject:

Ok Hulio, I have the Quad numbered R762717 coming from Canada,also another EHT number R7627165
What Splitter do I need now so the F*****g thing does not end up looking like that that boat !!

Hulio · Joined: 15 Apr 2006 Posts: 494 Location: Belgium

No problem Case, time to finaly use those ceiling mounts with pulley system Very Happy

CasetheCorvetteman · Joined: 09 Nov 2008 Posts: 6326 Location: Australia

Hulio · Joined: 15 Apr 2006 Posts: 494 Location: Belgium

Sorry, just back from work.
Well, you need the 762718 splitter.

dentree · Posted: Fri Jan 30, 2015 12:25 am Post subject:

I have 2 splitters one each from the Cine 8 and one from the BG 808 the id',s and original locations are as follows:

CINE 8 splitter no: 7617447/5

BG 808 splitter no: 7617447/2

Original Quad installation.

CINE 8 Quad no: R 762717 (Burned as in posts on page 2)

BG 808 Quad no: R 7622091 (metallic burning smell--no visible damage) when installed in CINE 8

with Splitter no:7617447/2

Original burnout combination numbers in Cine 8 Quad=R762717 + Splitter 7617447/5

Original combination numbers in BG 808 Quad =R7622091 + splitter 7617447/2 (these 2 worked fine in BG 808)
